สถานที่กำเนิด:
JIANGSU, จีน
ชื่อแบรนด์:
SWS
ติดต่อเรา
| Attribute | Value |
|---|---|
| Application | Well drilling |
| Features | API Standard |
| Production Capacity | 10000 pcs per month |
| Warranty | 1 Year |
| Weight (KG) | 100 |
| Core Components | Valve |
| Valve Type | Single & Double |
| Thread Type | STC LTC BTC EUE NUE XC |
| Size | 4"-20" |
| Material | Iron |
| Package | Wooden case or as per customer's requirement |
| Name | Size(in) | Bore O.D.(in) | Bore I.D.(in) | Min Bore Parameter(in) | Thread Type | lb(in²) |
|---|---|---|---|---|---|---|
| Float Collar | 5 1/2" | 6" | 4 3/4" | 2" | 5 1/2" LCSG | 4351 |
| Float Collar | 7" | 7 5/8" | 6 1/4" | 2 3/8" | 7" LCSG | 3626 |
| Float Collar | 9 5/8" | 10 5/8" | 8 5/8" | 2 3/8" | 9 5/8" LCSG | 3626 |
| Float Collar | 13 3/8" | 14 3/8" | 12 3/8" | 2 3/8" | 13 3/8" LCSG | 3626 |
| Float Shoe | 5 1/2" | 6" | 4 3/4" | 2" | 5 1/2" LCSG | 4351 |
| Float Shoe | 7" | 7 5/8" | 6 1/4" | 2 3/8" | 7" LCSG | 3626 |
| Float Shoe | 9 5/8" | 10 5/8" | 8 5/8" | 2 3/8" | 9 5/8" LCSG | 3626 |
| Float Shoe | 13 3/8" | 14 3/8" | 12 3/8" | 2 3/8" | 13 3/8" LCSG | 3626 |
ส่งคำถามของคุณโดยตรงถึงเรา
